Hobbing Machine for spur, Helical gear |
| Name |
Model |
Manufacturer |
Size |
Unit |
Remarks |
Gear Hobbing
machine |
|
Shibaura |
M50 xDia7000xH2000 |
1 |
|
| P2300 |
Pfauter (GER) |
M25*Dia1800*H1000 |
1 |
|
| ZFWZ-1250 |
Module (GER) |
M14*Dia1500*H490 |
1 |
Tangential divice |
| NDH-1200 |
Nihon Kikai |
M12*Dia1260*H450 |
1 |
Crowing device |
| ZFWZ-08 |
Module (GER) |
M10*Dia800*H400 |
1 |
Automatic |
| YNL-20 |
Yunil (KOR) |
M6*Dia660*H360 |
1 |
|
| P400 |
Pfauter (GER) |
M6*Dia400*H275 |
1 |
Crowing device |
| ZFWZ-400 |
Modul (GER) |
M6*Dia400*H275 |
1 |
|
|
|
Grinding machine for spur, Helical gear |
| Name |
Model |
Manufacturer |
Size |
Unit |
Remarks |
Gear Grinding
machine |
P3000G |
Gleson-Phauter |
M45 x D3020 x 1600B |
1 |
CNC & self testing |
| P1200G |
Gleson-Phauter |
M25 x D1200 x 800B |
1 |
CNC & self testing |
| RAPID800 |
Hoefler (GER) |
M25 x D800 x 800B |
1 |
CNC & self testing |
| RAPID1500 |
Hoefler (GER) |
M34*D1500 |
1 |
CNC & self testing |
| H800 |
Hoefler (GER) |
M14*Dia800*H240 |
1 |
CNC |
| ZSTZ-630 |
Niles (GER) |
M12*Dia630*H220 |
2 |
Program control |
| ZSTZ-315C3N |
Niles (GER) |
M10*Dia250*H120 |
2 |
Tapper grinding |
| RZ801 |
Reishauer (Swi) |
M9*Dia850 |
1 |
CNC |
| ZB |
Reishauer (Swi) |
M7*Dia700*H230 |
1 |
CNC |
| Spline Grinding machine |
KS803 |
Kapp (GER) |
Dia150*H800 |
1 |
Automatic |
|
|
Worm & Worm Hobbing, Grinding machine |
| Name |
Model |
Manufacturer |
Size |
Unit |
Remarks |
| Worm gear |
ZFWZ-08 |
Modul (GER) |
M14*Dia800*H560 |
1 |
6-axis CNC CTRL |
| Hobbing M/C |
full automatic |
| Worm & Thread |
HNC-35 |
Klingelnberg |
Dia350*1330L |
1 |
6-axis CNC CTRL |
| Grinding M/C |
full automatic |
Worm & Thread
milling machine |
NTM 1000 |
Nihonkikai |
Dia350*1500L |
1 |
|
| HHM-300S |
Pegmat |
Dia300*2000L |
1 |
|
| GFL 2000 |
WMW (GER) |
Dia200*2000L |
1 |
|
| HSF-160 |
Walztechnik |
Dia160*520L |
1 |
|
| Center Grinding |
SIXZB |
Knops (GER) |
Dia320*H1000 |
1 |
|
| Machine |
|
|
|
Internal gear Hobbing Machine |
| Name |
Model |
Manufacturer |
Size |
Unit |
Remarks |
| Gear shaper |
5M161 |
Stanko (USSR) |
M12*ST160*D1250 |
1 |
Internal gear cutting |
|
|
Turining, Boring, Lathe machine |
| Name |
Model |
Manufacturer |
Size |
Unit |
Remarks |
| Vertical |
TB-100 |
Shibaura |
SW1400*1070B |
1 |
|
| Turining Lathe |
TX16 |
Toshiba |
SW2000*1500B |
1 |
|
| |
TMS 2/40 |
O-M |
SW4000*1650B |
1 |
|
| |
TFM160 |
O-M |
SW1880*h2900 |
2 |
CNC |
| Boring machine |
FANUC-110 |
KURAKI |
W1600*H1200 |
1 |
CNC, Dia. 110 |
| |
KBN-135 |
WIA |
W4000*H1250 |
1 |
CNC, Dia. 135 |
| Universal |
|
Mammut (GER) |
NO.4 |
1 |
|
| Milling machine |
|
Tongil |
NO.5 |
1 |
|
| Slotting machine |
MLS-300 |
Masuda (JPN) |
ST330*Dia570 |
1 |
|
| |
MLS-600 |
Masuda (JPN) |
ST600*Dia1200 |
1 |
|
| Centering machine |
|
Osakakosakusho |
Dia100*700L |
2 |
|
| High speed lathe |
PROTURN50 |
Hankuk (KOR) |
SW630*2200L |
1 |
CNC |
| 500 |
Unimab (FRA) |
SW500*800L |
1 |
CNC |
| SOMOR-500 |
SEAH |
SW400*1050L |
2 |
|
| WL-520 |
Whacheon |
SW580*1500L |
1 |
|
| Heavy duty lathe |
TEK5000 |
Dakisawa (JPN) |
SW1050*5000L |
1 |
|
| 4FLH-20 |
Fuji Seiki (JPN) |
SW1550*1500L |
1 |
|
| Radial drilling |
|
Nambuk |
Dia750 |
1 |
|
| machine |
BR-2000 |
Nambuk |
Dia2000 |
1 |
|
|
|
Tool Grinding Machine |
| Name |
Model |
Manufacturer |
Size |
Unit |
Remarks |
| Hob Sharpener |
AS 5V |
Kapp |
Dia155*700L |
1 |
HYD. Automatic |
| AS 9V |
Kapp |
Dia400*1250L |
1 |
|
| Cutter grinding |
CB-45 |
Yuraka (JPN) |
Dia150 - Dia460 |
1 |
|
| Tool Grinding |
|
Youngjin (KOR) |
|
1 |
|
| Surface grinding |
WGS-400 |
Woojin |
400*180 |
1 |
|
|
 |
|
Spur and Helical Gear Grinding |
| Max. Module |
45 |
| Max. P.C.D. |
3020mm |
| Max. Face Width |
1600mm |
| Max. Stroke |
1600mm |
| Quality |
AGMA 12Class (JIS 0 Class) |
|
|
Worm and Thread Grinding |
| Max. Module |
25 |
| Out Diameter |
350mm |
| Grinding Length |
600mm |
| Lead |
599mm |
| No. of Teeth |
1-99 |
| Quality |
AGMA 12 Class (JIS 0 Class) |
|
|
Worm and Gear Hobbing |
| Max. Module |
25 |
| Max. P.C.D |
2500mm |
| Quality |
Under D650mm : AGMA12class(JIS 0 class) |
| Over D650mm : AGMA9class (Jis 3 class) |
|
|
Internal Gear Shaping |
| Max. Module |
22 |
| Max. P.C.D |
1200mm |
| max. Face Width |
530mm |
| Quality |
AGMA 11class (JIS 1 class) |
|
|
Case Boring |
| Table Left-Right |
9580mm |
| Front-Back |
1500mm |
| Spindle top-bottom |
3000mm |
|
| |
